Jazzy® Carbon Max HD Powerchair

Description

Weighing just 14.5 kg and boasting a 181 kg weight capacity, the Jazzy® Carbon HD is a game-changing heavy-duty travel power wheelchair. It folds and locks into position in mere seconds and will keep you comfortable with a padded seat back and extra-wide foot platform.

Clinical Benefits

The Jazzy Carbon HD addresses a significant clinical gap for users who require a high weight capacity of up to 181 kg combined with a device light enough to transport without specialist equipment. Full front and rear suspension reduces vibration transmission during community use, supporting users managing back pain, joint sensitivity, or fatigue-related conditions. The wide 20″ padded seat and extra-wide foot platform provide the postural comfort and skin integrity support needed for extended daily use, while the 14.2 kg frame allows carers and family members to assist with vehicle loading without a hoist or modified transport.

Features:

  • Adjustable lap belt (standard)
  • Padded back storage pocket
  • Durable, lightweight carbon fibre frame
  • Mesh cup holder (Optional extra)
  • Compact base folds & unfolds for easy transport
  • Height adjustable foot platform
  • Latch for locking unit open or closed

Specifications:

  • Range Per Charge: Up to 20 km
  • Maximum Weight Capacity: 181 kg
  • Turning Radius: 92.5 cm
  • Maximum Speed: 6 km/h
  • Length & Width: L: 93.5 cm W: 67 cm
  • Weight Of Heaviest Piece: 14.6 kg
  • Seat Size Width and Depth: W: 51 cm x D: 51 cm (20"x20")
  • Ground Clearance: 2.5 cm (at motor)
  • High Back Seat To Floor Range: 48 cm fixed
  • Standard Electronics: YT Control
  • Drive Train: Two-motor, rear-wheel drive
  • Braking System: Regenerative & electro-mechanical
  • Front Tyres: 6.5" solid castors
  • Drive Wheels: 10.6" solid
  • Battery Requirements: (1) 20Ah, 24V (lithium-ion, 436.8Wh)
  • Battery Charger: Off-board, 2A (lithium-ion)
  • Battery Weight: 3.4 kg
  • Colour Options: Cherry Black Carbon

Warranty Information:

  • Frame: 5 years
  • Other components: 1 year

Read more

Product form

$5,999.00$5,199.00

✔ Best Price Guarantee* If you find a cheaper price, we'll beat it. Read full T&C's here.

  • Registered NDIS Provider
  • Best Price Guarantee!
  • Proudly Australian Owned & Operated

SKU: JAZZY-CARBON-MAX-HD
Barcode: 149463

Icon for image_placeholderBrochures & Manuals
Icon for image_placeholderProduct Specific Documents
No downloads available for this product.
Warranty:
Frame: 5 years, Other components: 1 year
AS/NZ or ISO Standard:
ISO 7176-4
Icon for questionHave a question about this product?

We'd love to hear from you. Complete the form below and our specialists will attend to your enquiry.

Send us a message!

Description

Weighing just 14.5 kg and boasting a 181 kg weight capacity, the Jazzy® Carbon HD is a game-changing heavy-duty travel power wheelchair. It folds and locks into position in mere seconds and will keep you comfortable with a padded seat back and extra-wide foot platform.

Clinical Benefits

The Jazzy Carbon HD addresses a significant clinical gap for users who require a high weight capacity of up to 181 kg combined with a device light enough to transport without specialist equipment. Full front and rear suspension reduces vibration transmission during community use, supporting users managing back pain, joint sensitivity, or fatigue-related conditions. The wide 20″ padded seat and extra-wide foot platform provide the postural comfort and skin integrity support needed for extended daily use, while the 14.2 kg frame allows carers and family members to assist with vehicle loading without a hoist or modified transport.

Features:

  • Adjustable lap belt (standard)
  • Padded back storage pocket
  • Durable, lightweight carbon fibre frame
  • Mesh cup holder (Optional extra)
  • Compact base folds & unfolds for easy transport
  • Height adjustable foot platform
  • Latch for locking unit open or closed

Specifications:

  • Range Per Charge: Up to 20 km
  • Maximum Weight Capacity: 181 kg
  • Turning Radius: 92.5 cm
  • Maximum Speed: 6 km/h
  • Length & Width: L: 93.5 cm W: 67 cm
  • Weight Of Heaviest Piece: 14.6 kg
  • Seat Size Width and Depth: W: 51 cm x D: 51 cm (20"x20")
  • Ground Clearance: 2.5 cm (at motor)
  • High Back Seat To Floor Range: 48 cm fixed
  • Standard Electronics: YT Control
  • Drive Train: Two-motor, rear-wheel drive
  • Braking System: Regenerative & electro-mechanical
  • Front Tyres: 6.5" solid castors
  • Drive Wheels: 10.6" solid
  • Battery Requirements: (1) 20Ah, 24V (lithium-ion, 436.8Wh)
  • Battery Charger: Off-board, 2A (lithium-ion)
  • Battery Weight: 3.4 kg
  • Colour Options: Cherry Black Carbon

Warranty Information:

  • Frame: 5 years
  • Other components: 1 year

Read more


Specification Table

Length (mm) 935
Width (mm) 670
Seat depth (mm) 510
Seat width (mm) 510
Safe working load (kg) 181
